Dimensions |
Width |
1,234 mm (48-9/16") |
|
|
Height |
151 mm (5-15/16") |
|
|
Depth |
456 mm (17-15/16") |
|
|
Weight |
Weight |
14.2 kg (31 lb, 5 oz) |
|
|
Packing Box |
Width |
1,460 mm (57-1/2") |
|
|
Height |
270 mm (10-5/8") |
|
|
Depth |
540 mm (21-1/4") |
|
|
Control Interface |
Keyboard |
Number of Keys |
76 |
|
|
Type |
Organ (FSX), Initial Touch/Aftertouch |
|
|
Touch Response |
Normal, Easy1, Easy2, Soft1, Soft2, Hard1, Hard2 |
|
|
Other Controllers |
Joystick |
Yes (Assignable) |
|
|
Control Knobs |
6 (Assignable, with LED gauge) |
|
|
Sliders |
9 Live Control sliders (Assignable, with LED gauge), Cross Fader |
|
|
Art. Switches |
3 |
|
|
Pitch Bend |
- |
|
|
Modulation |
- |
|
|
Display |
Type |
Main Display : TFT Color Wide VGA LCD | Sub Display: VA (Live Control view) |
|
|
Size |
Main Display : 800 x 480 dots (9 inch) | Sub Display: 512 x 48 dots |
|
|
Touch Screen |
Main Display : Yes |
|
|
Color |
Color |
|
|
Language |
Main Display: English, German, French, Spanish, Italian | Sub Display: English |
|
|
Panel |
Language |
English |
|
|
Voices |
Tone Generation |
Tone Generating Technology |
FM, AWM Stereo Sampling, AEM technology |
|
|
Polyphony |
Number of Polyphony (Max.) |
384 (128 for Preset AWM Voices + 128 for Expansion AWM Voices + 128 for FM Voices) |
|
|
Preset |
Number of Voices |
1,991 Voices + 75 Drum/SFX Kits |
|
|
Featured Voices |
106 S.Articulation2, 437 S.Articulation, 141 FM, 40 Sweet!, 81 Cool!, 188 Live!, 25 OrganFlutes, 123 MegaVoice, 11 Ambient Drums/SFX, 11 Revo Drums/SFX |
|
|
Compatibility |
XG |
Yes (for Song playback) |
|
|
GS |
- |
|
|
GM |
Yes (for Song playback) |
|
|
GM2 |
Yes (for Song playback) |
|
|
Expandability |
Expansion Voice |
Yes (approx. 3 GB) |
|
|
Editing |
Voice Set |
|
|
Part |
Right 1, Right 2, Right 3, Left |
|
|
Effects |
Types |
Reverb |
85 Preset + 30 User |
|
|
Chorus |
107 Preset + 30 User |
|
|
DSP |
363 Preset (with VCM) + 30 User |
|
|
Insertion Effect |
1-28: 363 Preset (with VCM) + 30 User |
|
|
Master Compressor |
5 Preset + 30 User |
|
|
Master EQ |
9 Preset + 30 User |
|
|
Part EQ |
28 Parts |
|
|
Others |
Mic effects: Noise Gate, Compressor, 3 Band EQ, Vocal Effect: 23 |
|
|
Arpeggio |
Yes |
|
|
Vocal Harmony |
Number of Presets |
Vocal Harmony: 54, Synth Vocoder: 20 |
|
|
Number of User Settings |
60 *The number is the total of Vocal Harmony and Synth Vocoder |
|
|
Accompaniment Styles |
Preset |
Number of Preset Styles |
800 |
|
|
Featured Styles |
720 Pro, 69 Session, 11 Free Play |
|
|
Fingering |
Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered, Full Keyboard, AI Full Keyboard |
|
|
Style Control |
INTRO × 3, MAIN VARIATION × 4, FILL × 4, BREAK, ENDING × 3 |
|
|
Other Features |
One Touch Setting (OTS) |
4 for each Style |
|
|
Chord Looper |
Yes |
|
|
Style Section Reset |
Yes |
|
|
Unison & Accent |
- |
|
|
Expandability |
Expansion Style |
Yes (Internal Memory) |
|
|
Expansion Audio Style |
Yes (Internal Memory) |
|
|
Compatibility |
Style File Format (SFF), Style File Format GE (SFF GE) |
|
|
Songs |
Preset |
Number of Preset Songs |
9 Demo Songs, 1 Preset Song |
|
|
Recording |
Number of Songs |
Unlimited (depends on the drive capacity) |
|
|
Number of Tracks |
16 |
|
|
Data Capacity |
Approx. 3 MB/Song |
|
|
Recording Function |
Quick Recording, Multi Recording, Step Recording |
|
|
Compatible Data Format |
Playback |
SMF (Format 0 & 1), XF |
|
|
Recording |
SMF (Format 0) |
|
|
Multi Pads |
Preset |
Number of Multi Pad Banks |
507 Banks x 4 Pads |
|
|
Audio |
Audio Link |
Yes |
|
|
Functions |
Registration |
Number of Buttons |
10 |
|
|
Control |
Registration Sequence, Freeze |
|
|
Playlist |
Number of Records |
2500 (max.) Records per Playlist file |
|
|
Lesson/Guide |
Lesson/Guide |
Follow Lights, Any Key, Karao-Key, Your Tempo |
|
|
Search |
Yes |
|
|
Demo/Help |
Demonstration |
Yes |
|
|
Overall Controls |
Metronome |
Yes |
|
|
Tempo Range |
5 - 500, Tap Tempo |
|
|
Transpose |
-12 – 0 – +12 |
|
|
Tuning |
414.8 – 440 – 466.8 Hz (approx. 0.2 Hz increments) |
|
|
Octave Button |
Yes |
|
|
Scale Type |
9 types |
|
|
Sub Scale Setting |
Yes |
|
|
USB Audio Interface |
Yes |
|
|
Bluetooth |
Yes (Audio) * May not have this functionality depending on the country |
|
|
Miscellaneous |
Direct Access |
Yes |
|
|
Text Display Function |
Yes |
|
|
Wallpaper Customization |
Yes |
|
|
Display Out |
HDMI (1,280 × 720p max.) |
|
|
Voices |
Harmony/Echo |
Yes (with Arpeggio) |
|
|
Panel Sustain |
Yes |
|
|
Mono/Poly |
Yes |
|
|
Voice Information |
Yes |
|
|
Styles |
Style Creator |
Yes |
|
|
OTS Information |
Yes |
|
|
Songs |
Score Display Function |
Yes |
|
|
Lyrics Display Function |
Yes |
|
|
Song Creator |
Yes |
|
|
Multi Pads |
Multi Pad Creator |
Yes |
|
|
Audio Recorder/Player |
Recording Time (max.) |
approx. 0.8 GB (80 minutes) per Song |
|
|
Recording |
WAV (44.1 kHz, 16 bit, stereo) |
|
|
Playback |
WAV (44.1 kHz, 16 bit, stereo), MP3 (44.1/48.0 kHz, 64/96/128/256/320 kbps or VBR, mono/stereo) |
|
|
Lyrics Display Function |
Yes |
|
|
Time Stretch |
Yes |
|
|
Pitch Shift |
Yes |
|
|
Vocal Cancel |
Yes |
|
|
Storage and Connectivity |
Storage |
Internal Memory |
Yes (approx. 15 GB) |
|
|
External Drives |
USB flash drive |
|
|
Connectivity |
Headphones |
Standard stereo phone jack (PHONES) |
|
|
FOOT PEDAL |
1 (SUSTAIN), 2 (ART.1), 3 (VOLUME), Function assignable |
|
|
Microphone |
Yes (Combo Jack), Phantom Power (+48 V) available |
|
|
MIDI |
MIDI A (IN/OUT), MIDI B (IN/OUT) |
|
|
AUX IN |
L/L+R, R Standard phone jack |
|
|
LINE OUT |
MAIN (L/L+R, R), SUB (1,2), SUB (3,4/AUX OUT) Standard phone jack |
|
|
USB TO DEVICE |
Yes (x 3) |
|
|
USB TO HOST |
Yes |
|
|
Wireless LAN |
Yes (*) Standards: IEEE802.11b/g/n (IEEE802.11n 5 GHz: not compatible), Range of transmit frequency (channels): Models for Europe and Brazil: 2401–2483 MHz (channels 1–13) Others: 2401–2473 MHz (channels 1–11), Maximum RF output power: 14 dBm, Security: WEP, WPA-PSK (TKIP), WPA-PSK (AES), WPA2-PSK (AES), WPA/WPA2 mixed PSK, SAR value: 0.258 W/kg * May not be included, depending on your area. Check with your Yamaha dealer. |
|
|
Amplifiers and Speakers |
Amplifiers |
- |
|
|
Speakers |
- |
|
|
Power Supply |
Power Supply |
AC power cord |
|
|
Power Consumption |
37 W |
|
|
Auto Power Off Function |
Yes |
|
|
Accessories |
Included Accessories |
Owner’s Manual, AC power cord, Music Rest, two Music Rest brackets |
|
|
