| Body |
Color |
|
Black |
|
| Size/Weight |
| Dimensions |
Width |
|
1004 mm |
|
| Height |
|
134 mm |
|
| Depth |
|
410 mm |
|
| Weight |
Weight |
|
8.1 kg |
|
| Packing Box |
Width |
|
1,110 mm (43-11/16") |
|
| Height |
|
231 mm (9-1/8") |
|
| Depth |
|
528 mm (20-13/16") |
|
| Control Interface |
| Keyboard |
Number of Keys |
|
61 |
|
| Type |
|
Organ, Initial Touch |
|
| Touch Response |
|
Normal, Soft 1, Soft 2, Hard 1, Hard 2 |
|
| Other Controllers |
Joystick |
|
- |
|
| Control Knobs |
|
2 (assignable) |
|
| Pitch Bend |
|
Yes |
|
| Modulation |
|
Yes |
|
| Display |
Type |
|
TFT Color WQVGA LCD |
|
| Size |
|
480 x 272 dots (4.3 inch) |
|
| Touch Screen |
|
- |
|
| Color |
|
Color |
|
| Language |
|
English, German, French, Spanish, Italian, Japanese |
|
| Panel |
Language |
|
English |
|
| Voices |
| Tone Generation |
Tone Generating Technology |
|
AWM Stereo Sampling |
|
| Polyphony |
Number of Polyphony (Max.) |
|
128 |
|
| Preset |
Number of Voices |
|
850 Voices + 43 Drum/SFX Kits + 480 XG Voices |
|
| Featured Voices |
|
73 S.Articulation!, 27 MegaVoice, 27 Sweet!, 64 Cool!, 71 Live! |
|
| Compatibility |
XG |
|
Yes (for Song playback) |
|
| GS |
|
Yes (for Song playback) |
|
| GM |
|
Yes |
|
| GM2 |
|
Yes |
|
| Expandability |
Expansion Voice |
|
Yes (approx. 100MB max.) |
|
| Editing |
|
Voice Set |
|
| Part |
|
Right 1, Right 2, Left |
|
| Effects |
| Types |
Reverb |
|
52 Preset + 30 User |
|
| Chorus |
|
106 Preset + 30 User |
|
| DSP |
|
295 Preset + 30 User |
|
| Insertion Effect |
|
- |
|
| Master Compressor |
|
5 Preset + 30 User |
|
| Master EQ |
|
5 Preset + 30 User |
|
| Part EQ |
|
27 Parts |
|
| Others |
|
Mic effects: Noise Gate x 1, Compressor x 1, 3 Band EQ |
|
| Arpeggio |
|
Yes |
|
| Vocal Harmony |
Number of Presets |
|
- |
|
| Number of User Settings |
|
- |
|
| Accompaniment Styles |
| Preset |
Number of Preset Styles |
|
415 |
|
| Featured Styles |
|
372 Pro Styles, 32 Session Styles, 10 DJ Styles, 1 Free Play |
|
| Fingering |
|
Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered, Full Keyboard, AI Full Keyboard, Smart Chord |
|
| Style Control |
|
INTRO x 3, MAIN VARIATION x 4, FILL x 4, BREAK, ENDING x 3 |
|
| Other Features |
One Touch Setting (OTS) |
|
4 for each Style |
|
| Chord Looper |
|
- |
|
| Style Section Reset |
|
Yes |
|
| Unison & Accent |
|
Yes |
|
| Expandability |
Expansion Style |
|
Yes (Internal Memory) |
|
| Expansion Audio Style |
|
- |
|
| Compatibility |
|
Style File Format (SFF), Style File Format GE (SFF GE) |
|
| Songs |
| Preset |
Number of Preset Songs |
|
3 Sample Songs |
|
| Recording |
Number of Songs |
|
- |
|
| Number of Tracks |
|
16 |
|
| Data Capacity |
|
Approx. 1 MB/Song |
|
| Recording Function |
|
Quick Recording, Multi Track Recording |
|
| Compatible Data Format |
Playback |
|
SMF (Format 0 & 1), XF |
|
| Recording |
|
SMF (Format 0) |
|
| Multi Pads |
| Preset |
Number of Multi Pad Banks |
|
188 Banks x 4 Pads |
|
| Audio |
Audio Link |
|
Yes |
|
| Functions |
| Registration |
Number of Buttons |
|
8 |
|
| Control |
|
Registration Sequence, Freeze |
|
| Playlist |
Number of Records |
|
500 (max.) Records per Playlist file |
|
| Lesson/Guide |
Lesson/Guide |
|
Follow Lights, Any Key, Karao-Key, Your Tempo |
|
| Search |
|
Registration Bank |
|
| Demo/Help |
Demonstration |
|
Yes |
|
| Overall Controls |
Metronome |
|
Yes |
|
| Tempo Range |
|
5 - 500, Tap Tempo |
|
| Transpose |
|
-12 – 0 – +12 |
|
| Tuning |
|
414.8 – 440.0 – 466.8 Hz |
|
| Octave Button |
|
Yes |
|
| Scale Type |
|
9 types |
|
| Sub Scale Setting |
|
- |
|
| Bluetooth |
|
- |
|
| Miscellaneous |
Direct Access |
|
Yes |
|
| Text Display Function |
|
Yes |
|
| Wallpaper Customization |
|
- |
|
| Display Out |
|
- |
|
| Voices |
Harmony/Echo |
|
Yes (with Arpeggio) |
|
| Panel Sustain |
|
Yes |
|
| Mono/Poly |
|
Yes |
|
| Voice Information |
|
Yes |
|
| Styles |
Style Creator |
|
Yes |
|
| OTS Information |
|
Yes |
|
| Songs |
Score Display Function |
|
Yes |
|
| Lyrics Display Function |
|
Yes |
|
| Song Creator |
|
Yes |
|
| Multi Pads |
Multi Pad Creator |
|
Yes |
|
| Audio Recorder/Player |
Recording Time (max.) |
|
80 minutes/Song |
|
| Recording |
|
*only on USB .wav (WAV format: 44.1 kHz sample rate, 16 bit resolution, stereo) |
|
| Playback |
|
*only on USB .wav (WAV format: 44.1 kHz sample rate, 16 bit resolution, stereo) |
|
| Lyrics Display Function |
|
- |
|
| Time Stretch |
|
Yes |
|
| Pitch Shift |
|
Yes |
|
| Vocal Cancel |
|
Yes |
|
| Storage and Connectivity |
| Storage |
Internal Memory |
|
Yes (approx. 20 MB max.) |
|
| External Drives |
|
USB flash drive |
|
| Connectivity |
Headphones |
|
Yes |
|
| FOOT PEDAL |
|
1 (Sustain), 2 (Unison), Function Assignable |
|
| Microphone |
|
Microphone x 1 |
|
| MIDI |
|
- |
|
| AUX IN |
|
Stereo mini jack |
|
| LINE OUT |
|
MAIN OUTPUT(L/L+R, R) |
|
| USB TO DEVICE |
|
Yes |
|
| USB TO HOST |
|
Yes |
|
| Amplifiers and Speakers |
| Amplifiers |
|
15 W x 2 |
|
| Speakers |
|
12 cm x 2 |
|
| Power Supply |
| Power Supply |
|
PA-300C or an equivalent recommended by Yamaha |
|
| Power Consumption |
|
17 W |
|
| Auto Power Off Function |
|
Yes |
|
| Accessories |
| Included Accessories |
|
Owner's Manual, Online Member Product Registration, Music Rest, AC Adaptor (may not be include depending on your area. Check with your Yamaha dealer.) |
|
