Sound
AN-X Engine: Two filters, 10 filter types, pulse width modulation, oscillator self sync, ring modulation, FM and wave shaper, wave folder, voltage drift and aging settings to simulate vintage synth behavior
AWM2: Up to 128 Elements per Part for layered, detailed, and realistic sounds
Polyphony: 268 notes total (128 AWM2, 128 FM-X, 12 AN-X)
Preset wave and flash memory upgrade: 10.7 GB AWM2 memory, 1.9 GB user flash memory
VCM Rotary Speaker: Simulates rich motion of classic rotary speaker cabinet
Control
Dedicated Part and Scene Control: Control 8 Parts per Performance with dedicated buttons
High Resolution Control: Knobs, Super Knob, Pitch Bend, Mod Wheel, and Sound Engine operate with fine resolution
Motion Control Synthesis Engine: Motion Sequences, Super Knob, Envelope Follower, and other advanced tools for dynamic sound design
8 Faders, 4 Knobs, 4 Pedal Inputs, 6 Display Knobs
Workflow
Expanded Softsynth Plugin (ESP): Full integration with DAWs, allows creating, editing, and mixing performances without hardware
Faster, Intuitive Navigation: Color touch screen, 6 display knobs, stereo A/D input with 2 insertion effects
USB MIDI 2.0 and Multichannel Audio Interface: 10-output / 4-input interface at 44.1 kHz, supports high-resolution MIDI data
Cubase AI: Entry-level DAW software included for recording, editing, and mixing
Dedicated DAW Remote Button: Control DAWs (Cubase, Logic, ProTools, Live) as a hardware controller
Dimenzije
Širina: 882 mm
Visina: 117 mm
Dubina: 347 mm
Težina
6.6 kg
Klavijatura
Broj dirki: 61
Tip: Semi-weighted FSB Keyboard
Initial Touch: Da
Aftertouch: Ne
Tone Generator
Tone Generator: Motion Control Synthesis Engine AMW2: 128 Elements (max.), FM-X: 8 Operators, 88 Algorithms, AN-X: 3 Oscillators, 1 Noise
Maksimalna polifonija: AWM2: 128, FM-X: 128, AN-X: 12
Multi-timbral kapacitet: 16 delova (internal), Audio Input Parts (A/D, USB) *1 stereo Part
Wave memorija: Preset: 10.7 GB, User: 1.9 GB
Performansi: 3,427
Filter: 18 tipova
Efekti: Reverb x 13, Variation x 88, Insertion A x 88, Insertion B x 89, Master Effect x 26, Master EQ (5 bands), 1st part EQ (3 bands), 2nd part EQ (2 bands)
Performance Recorder
Note Capacity: Approx. 130,000 notes per song/pattern, Store area: approx. 520,000 notes
Note Resolution: 480 ppq
Tempo: 5 – 300 BPM
Sequence formats: MONTAGE M/MODX M original format, SMF formats 0,1
Arpeggio: 8 Parts simultaneous, Preset: 10,922+ types, User: 256 types
Sequencer
Patterns: 128
Pattern tracks: 16 Sequence tracks
Pattern Recording type: Real time replace, Real time overdub
Songs: 128
Song tracks: 16 Sequence tracks, Tempo track, Scene track
Song recording type: Real time replace, Real time overdub, Real time punch in/out
Funkcije
USB audio interface: [44.1 kHz] Input: 4 channels, Output: 10 channels; [44.1/48/96 kHz] Input: 2 channels, Output: 2 channels
Ostalo
Controllers: Master Volume, A/D Input Gain knob, Pitch Bend wheel, Modulation wheel, Control Slider x 8, Knob x 4, Super knob, Display knob x 6, Portamento knob, Data Dial, Assignable switch x 2, MSEQ trigger switch, Portamento switch, Keyboard hold switch
Display: 7" TFT Color Wide VGA LCD touch screen
Connectors: USB [TO DEVICE], USB [TO HOST], MIDI [IN]/[OUT], FOOT CONTROLLER [1]/[2], FOOT SWITCH [SUSTAIN]/[ASSIGNABLE], OUTPUT [L/MONO]/[R], PHONES, A/D INPUT [L/MONO]/[R]
Power Consumption: 19 W
Accessories: AC adaptor PA-300C, Quick guide, Cubase AI download info, Expanded Softsynth plugin info, Manuals download info, Welcome card
Live Sets: Preset 256, User 2,048
