SOUND GENERATOR
• Piano Sound: SuperNATURAL Piano
• Max. Polyphony: 256
• Tones:
◦ Piano: 12 tones
◦ E.Piano: 20 tones
◦ Other: 24 tones
KEYBOARD
• Keyboard: 88 keys (PHA-4 Standard Keyboard: with Escapement and Ivory Feel)
SPEAKER SYSTEM
• Speakers: 12 cm x 2
• Rated Power Output: 11 W x 2
BLUETOOTH
• Audio: Bluetooth Ver 3.0 (Supports SCMS-T content protection)
• MIDI: Bluetooth Ver 4.0
COMPATIBLE ANDROID / IOS APPS (ROLAND)
• Compatible Android / iOS Apps (Roland):
◦ Roland Piano App
◦ Piano Designer
◦ *Support for the app may be terminated without prior notice.
DATA PLAYBACK
• Playable Software:
◦ Standard MIDI Files (Format 0, 1)
◦ Audio File (WAV: 44.1 kHz, 16-bit linear format, MP3: 44.1 kHz, 64 kbps - 320 kbps, requires USB flash drive)
RECORDER
• Recordable Software: Standard MIDI Files (Format 0, 1 part, Approx. 70,000 notes memory)
• Internal Songs: 30 Songs
TUNING, VOICING
• Touch Sensitivity: Key Touch: 5 types, fixed touch
• Master Tuning: 415.3--466.2 Hz (adjustable in increments of 0.1 Hz)
• Effects:
◦ Ambience
◦ Brilliance
◦ Only for organ tones:
◦ Rotary Speaker Effect
• Piano Designer (Settings can be changed only through the app.):
◦ Lid
◦ String Resonance
◦ Damper Resonance
◦ Key Off Resonance
◦ Single Note Tuning
◦ Single Note Volume
◦ Single Note Character
◦ Temperament
◦ Temperament Key
CONVENIENT FUNCTIONS
• Convenient Functions:
◦ Metronome (adjustable Tempo/Beat/Volume/Tone)
◦ Transpose (Keyboard: in semitones)
◦ Dual
◦ Split (split point adjustable)
◦ Twin Piano
◦ Tone Demo
◦ Speaker volume and Headphones volume automatically select function
◦ Speaker Auto Mute
◦ Speaker switch
◦ Auto Off
OTHER
• Connectors:
◦ DC In jack
◦ Pedal1 (Damper) jacks (capable of continuous detection when optional pedal connected)
◦ Pedal2 (Damper, Sostenuto, Soft) jacks (capable when dedicated pedal board connected)
◦ Output (L/Mono, R) jacks: 1/4-inch phone type
◦ USB Computer port: USB B type (supports USB MIDI/AUDIO)
◦ USB Memory port: USB A type
◦ Phones jack x 2: Stereo miniature phone type, Stereo 1/4-inch phone type
• Power Supply: AC adaptor
• Power Consumption:
◦ 16W (When using the included AC adaptor)
◦ *Approximate power consumption when playing the piano at medium volume: 4W
◦ Power consumption when sound has not been played after power-on: 3W
ACCESSORIES
• Accessories:
◦ Owner's Manual
◦ Leaflet "USING THE UNIT SAFELY"
◦ AC adaptor
◦ Power cord
◦ Music rest
◦ Pedal switch (DP-2)
OPTION (SOLD SEPARATELY)
• Option (sold separately):
◦ Dedicated stand: KSC-70
◦ Dedicated pedal board: KPD-70
◦ Keyboard stand: KS-10Z, KS-12, KS-20X
◦ Damper pedal: DP series
◦ Carrying Bag: CB-88RL, CB-76RL, CB-B88V2, SC-G76W3
◦ Headphones
SIZE & WEIGHT
• Dimensions:
◦ Detached music rest:
◦ 1,300 (W) x 284 (D) x 151 (H) mm
◦ 51-3/16 (W) x 11-3/16 (D) x 6 (H) inches
◦ FP-30X with KSC-70 and music rest and dedicated stand:
◦ 1,300 (W) x 344 (D) x 931 (H) mm
◦ 51-3/16 (W) x 13-9/16 (D) x 36-11/16 (H) inches
• Weight:
◦ 14.8 kg, 32 lbs 11 oz (FP-30X with music rest)
◦ 23.0 kg, 50 lbs 12 oz (FP-30X with KSC-70, KPD-70, and music rest)
