These amplifiers offer high, stable power output and a high efficiency factor on the high performance level and are therefore the ideal choice for driving a multitude of mobile and club systems. SL series power amplifiers are equipped with a comprehensive protection package and dynamic limiters.
The integrated, switchable Low-Pass Notch filter (a typical DYNACORD special feature) corrects the frequency response and optimizes the transient behaviour of loudspeakers.
Maximum Midband Output Power, THD = 1%, 1 kHz, Dual Channel - 2 Ω - 1250 W, 4 Ω - 900 W, 8 Ω - 550 W
Maximum Single Channel Output Power, Dynamic-Headroom, IHF-A - 2 Ω - 2450 W, 4 Ω - 1400 W, 8 Ω - 700 W
Maximum Bridged Output Power, THD = 1%, 1 kHz - 4 Ω - 2800 W, 8 Ω - 1800 W
Input Sensitivity, rated power @ 8 Ω, 1 kHz - +5.1 dBu (1.39 Vrms)
Maximum Input Level - +21 dBu (8.69 Vrms)
Voltage Gain, ref. 1 kHz - 32.0 dB
Frequency Response, ref. 1 kHz - 10 Hz...40 kHz (±1 dB)
Output Stage Topology - Class H
Dimensions (W x H x D), mm - 483 x 88.1 x 421.5
Weight - 16.3 kg (35.9 lbs)
