Dvosistemska pasivna zvučna kutija sa 15" zvučnikom.
1" izlaz/2" diafragma titaniumskog kompresionog drajvera.
Pri frekvenciji od 50 Hz do 18000 Hz, impedance 8 Ohma, trapeziodnog oblika za horizontalnu ili vertikalnu postavku. Konstantne snage 400W, dimezija 708x478x402 mm i težine22 kg.
| GENERAL INFO | |
| System type | 15" 2-way passive |
| Frequency response +/- 3db | 50-18kHz |
| Sensitivity (db 1w@1m) | 97dB |
| System impedance | 8 ohms |
| Maximum SPL Peak dB | 129dB |
| POWER HANDLING (Watts) | |
| Continuous RMS | 400 |
| Program | 800 |
| Peak | 1600 |
| LF DRIVER | |
| Lf driver size mm / inches | 1x15" |
| Lf voice coil size | 75mm/3" |
| HF SECTION | |
| Hf voice coil size | 51mm/2" |
| Hf type | Compression Driver |
| Hf diaphragm material | Titanium |
| Horn dispersion (H x V) | 90 x 60 |
| Hf exit size mm / inches | 25mm/1" |
| Hf horn shape | EWGT - Elliptical Waveguide |
| Hf peak indicator | Peak LED ring in horn throat |
| CROSSOVER SECTION | 2-way |
| Crossover Frequency / Filter | 1.8kHz / 12dB per oct. |
| Hf driver protection | DTFT - Dynamic Thermal Filament (2 x SK3 Bulb) |
| PHYSICAL FEATURES | |
| Finish | Black or White |
| Handle quantity | 2 carry handles (one on each side) |
| Suspension points | (10) M8 points for safe flown applications, (4) M8 inserts on bottom in OmniMountR 60.0-type footprint |
| Stand adapter - BOTTOM | Pole-mount receptacle with lock screw, Optional wall-mount bracket |
| Enclosure type | Molded Polypropylene |
| Enclosure shape | Trapezoidal for vertical array and horizontal stage monitor applications |
| IN / OUT PANEL (speaker Level) | |
| Input connector | 2 x 1/4" jacks and2 x SpeakonT |
| DIMENSIONS & WEIGHT | |
| Height ( mm / ins ) | 708mm/27.9" |
| Width Front / Rear / mm / ins | 477.8mm/18.8" |
| Depth ( mm / ins ) | 401.77mm/15.8" |
| Net weight ( kg / lbs ) | 22kg/48.4 lbs |
| Gross weight ( kg / lbs ) | 25kg/55 lbs |
