| Keyboard |
| Keyboard |
88 keys (PHA II with Escapement) |
| Touch Sensitivity |
Touch: 5 levels, Fixed Touch |
| Keyboard Mode |
Whole, Dual (volume balance adjustable), Split (split point adjustable), Twin Piano |
| Sound Generator |
| Piano Sound |
SuperNATURAL Piano Sound |
| Sound Generator |
Conforms to GM2/GS/XG Lite |
| Maximum Polyphony |
128 voices |
| Tones |
337 tones (including 8 drum sets, 1 SFX set) |
| Temperament |
8 types, selectable temperament Key |
| Stretched Tuning |
On/Off |
| Master Tuning |
415.3 Hz to 466.2 Hz (adjustable in increments of 0.1 Hz) |
| Transpose |
Key Transpose: -6 to +5 (in semitones)
Playback Transpose (with Audio CD/Audio File): -6 to +5 (in semitones) |
| Effects |
| |
Reverb (Off, 10 levels) |
| Only for Piano Tones |
Damper Resonance (Off, 10 levels)
String Resonance (Off, 10 levels)
Key Off Resonance (Off, 10 levels) |
| Only for Organ Tones |
Rotary Speaker Effect (Slow/Fast) |
| Recorder |
| Tracks |
3 tracks |
| Song |
Recorder section: 1 song
Internal Memory: Maximum 99 songs |
| Note Storage |
Approx. 30,000 notes |
| Control |
Song Select, Play/Stop, Rec, Rewinding, Fast-forwarding, Previous song, Next song, Track Mute, Mute Volume, Tempo, Tempo Mute, All Songs Play, Count-in, Song Volume, Center Cancel (only for Audio playback) |
| Tempo |
Quarter note = 10 to 500
Audio Playback Speed: 75 % to 125 % |
| Resolution |
120 ticks per quarter note |
| Metronome |
Tempo: Quarter note = 10 to 500
Beat: 2/2, 0/4, 2/4, 3/4, 4/4, 5/4, 6/4, 7/4, 3/8, 6/8, 9/8, 12/8
Volume: 11 levels |
| Internal Memory |
| Songs |
Maximum 99 songs |
| Save Song |
Standard MIDI Files (Format 0) |
| External Memory |
| External Storage |
USB Flash Memory
Floppy Disk (when using optional floppy disk drive) |
| Playable Software |
Standard MIDI Files (Format 0/1)
Roland Original Format (i-Format)
Audio File (WAV 44.1 kHz/16-bit linear format)
Audio CDs (CD-DA) (when using optional CD drive) |
| Save Song |
Standard MIDI Files (Format 0) |
| Others |
| Internal Songs |
72 songs |
| Rated Power Output |
12 W x 2 |
| Volume Level (SPL) |
105 dB (*)
* These figures were measured according to the method that is based on Roland's technical standard |
| Speakers |
12 cm x 2 (with Speaker box) |
| Display |
7-segments, 3 characters (LED) |
| Control |
Volume |
| Pedals |
Damper (capable of continuous detection)
Soft (capable of continuous detection, function assignable)
Sostenuto (function assignable) |
| Other Functions |
Panel Lock
V-LINK |
| Connectors |
DC inlet, Input jacks (L/Mono, R), Output jacks (L/Mono, R), MIDI connectors (In, Out), Phones jack (Stereo) x 2, External Memory connector |
| Power supply |
DC 12 V |
| Power Consumption |
24 W |
| Accessories |
Owner's Manual, AC Adaptor, Power Cord (for AC Adaptor), Headphones Hook, Cord Clamps, Stabilizer |
| Options |
Headphones (RH-A30, RH-300, RH-L20, RH-5), USB Flash Memory (M-UF2G), USB Floppy Disk Drive (FD-01A), USB CD Drive (CD-01A) |
| Size and Weight ( with lid close ) |
| Width |
|
| Depth |
|
| Height |
|
| Weight |
|
| Size and Weight ( with lid open ) |
| Width |
|
| Depth |
|
| Height |
|
| Weight |
|
