Description
This 5-channel mixer holds a 2x 500W amplifier. Giving the user a complete unit as base for this setup. With 4 microphone and line inputs it's ideal for live performers on stage. 16 digital effects give you plenty of room to fine tune your sound.
Highlights
- 2x 500W power amplifier
- MP3 player with USB port and SD slot
- Using BT wireless technology for audio streaming
- +48V phantom power
- Single 5 band EQ
- 16 digital effects (DSP)
- PFL per channel
- RCA record output
- Tone control per channel
- 6.3mm outputs (L+R)
Brand: Vonyx
Product Series: AM Series
Colour: Black
Number of Channels: 5
Frequency Response: 20 Hz – 20,000 Hz
Playback
Playback Options: Bluetooth streaming, SD card, USB
Sound Editing
Equalizer: 2-band EQ for microphone/line input
Audio Specifications
Signal-to-Noise Ratio (Main): > 90 dB
Total Harmonic Distortion (THD, Main): < 0.1%
Headphone Output Level: 300 mW
Features
Built-in amplifier
Effects processor
Playback function
Connections
Input Connections
XLR
USB-A
SD card
RCA
6.3 mm jack
Output Connections
6.3 mm jack
XLR
Power Supply
Voltage: 220–240 V AC
Frequency: 50 Hz
Dimensions and Weight
Dimensions (W × D × H): 320 × 300 × 140 mm
Weight: 5.9 kg
