The Squier Sonic® Stratocaster® HSS is ready to launch any musical adventure into warp speed, offering iconic Fender® style and inspiring tone for players at any stage. This Strat® sports a slim and inviting "C"-shaped neck profile and a thin, lightweight body for optimal playing comfort. The HSS pickup configuration denotes a humbucking (H) bridge pickup for substantial, high-output tone, complimenting the single-coil (S) neck and middle pickups that chime with crystal clarity. Further details of this model include a tremolo bridge for expressive vibrato effects, sealed-gear tuning machines for smooth, accurate tuning and durable chrome-plated hardware that is sure to catch the spotlight.
ACCESSORIES
• Saddle Height Wrench: 1.5mm Hex Wrench
• Truss Rod Wrench: 4 mm Hex (Allen)
BODY
• Body: Poplar
• Body Finish: Gloss Polyurethane
• Body Material: Poplar
• Body Shape: Stratocaster®
ELECTRONICS
• Bridge Pickup: Ceramic Humbucker
• Controls: Master Volume, Tone 1. (Neck/Middle Pickups), Tone 2. (Bridge Pickup)
• Middle Pickup: Ceramic Single-Coil
• Neck Pickup: Ceramic Single-Coil
• Pickup Configuration: HSS
• Switching: 5-Position Blade
◦ Position 1. Bridge Pickup
◦ Position 2. Bridge and Middle Pickup
◦ Position 3. Middle Pickup
◦ Position 4. Middle and Neck Pickup
◦ Position 5. Neck Pickup
GENERAL
• Color: 2-Color Sunburst
• Orientation: Right-Hand
• Product Name: FSR Squier Sonic® Stratocaster® HSS, Maple Fingerboard, White Pickguard, 2-Color Sunburst
• Series: Squier Sonic®
HARDWARE
• Bridge: 6-Saddle Vintage-Style Synchronized Tremolo with Block Saddles
• Control Knobs: White Plastic
• Hardware Finish: Chrome
• Neck Plate: 4-Bolt Squier®
• Pickguard: 1-Ply White
• Pickup Covers: White
• Strap Buttons: Vintage-Style
• Strings: Nickel Plated Steel (.009-.042 Gauges)
• Switch Tip: White
• Tuning Machines: Die-Cast Sealed
MEASUREMENTS
• Fret Size: Narrow Tall
• Scale Length: 25.5" (648 mm)
MISCELLANEOUS
• Style: 2 Single-Coil / 1 Humbucking
NECK
• Fingerboard Material: Maple
• Fingerboard Radius: 9.5" (241 mm)
• Headstock: Stratocaster®
• Neck Construction: Bolt-On
• Neck Finish: Satin Urethane
• Neck Material: Maple
• Neck Shape: "C" Shape
• Number of Frets: 21
• Nut Material: Synthetic Bone
• Nut Width: 1.650" (42 mm)
• Position Inlays: Black Dot
• Side Dots: Black
• String Nut: Synthetic Bone
• Truss Rod: Head Adjust
• Truss Rod Nut: 4 mm Hex
