Nyatoh neck
The Nyatoh neck provides a rich mid-low end.
Gibraltar Performer bridge
The Gibraltar Performer bridge provides rich sustain and tuning stability. The low-positioned saddles promise comfortable playability.
Rosewood fretboard
Rosewood fretboard provides a well-balanced solid tone with a focused mid range.
Infinity R H-H pickups
Ibanez Infinity pickups deliver an accurate and tight sound with excellent dynamics. Even under heavy settings, they do not lose tonal clarity.
Quik Change III Tailpiece
The Quik Change III tailpiece enables faster and easier string changing.
Neck type AM ArtcoreNyatohset-in neck
top/back/side Linden top Linden backLinden sides
fretboard Bound Rosewood fretboardWhite dot inlay
fret Medium frets
number of frets 22
bridge Gibraltar Performer bridge
string space 10.5mm
tailpiece Quik Change III tailpiece
neck pickup Infinity R (H) neck pickupPassive/Ceramic
bridge pickup Infinity R (H) bridge pickupPassive/Ceramic
factory tuning 1E,2B,3G,4D,5A,6E
string gauge .010/.013/.017/.030/.042/.052
hardware color Chrome
NECK DIMENSIONS
Scale : 628mm
a : Width 43mm at NUT
b : Width 57mm at 22F
c : Thickness 21mm at 1F
d : Thickness 24mm at 9F
Radius : 305mmR
BODY DIMENSIONS
a : Length 17 5/8"
b : Width 14 1/2"
c : Max Depth 2 5/8"
