Maple neck
The Maple neck provides stability and bright tonal character.

Phat II EQ
Phat II active bass boost adds additional low-end power.

B10 bridge
The B10 bridge allows fully adjustable intonation and solid tuning stability.
neck type	GSR4  Maple neck
top/back/body	Spalted Maple topPoplar body
fretboard	Jatoba fretboardWhite dot inlay
fret	Medium frets
bridge	B10 bridge
string space	19mm
neck pickup	Dynamix P neck pickupPassive
bridge pickup	Dynamix J bridge pickupPassive
equaliser	Phat II EQ
factory tuning	1G,2D,3A,4E
string gauge	.045/.065/.080/.100
hardware color	Black

NECK DIMENSIONS

Scale :	864mm/34"
a : Width	41mm at NUT
b : Width	62mm at 22F
c : Thickness	21mm at 1F
d : Thickness	22mm at 12F
Radius :	305mmR
