MOOER Digital PreAMP Live

 Contains 12 independent preamp channels with intuitive, familiar switching controls

* Pre/Post BOOSTER and adjustable Pre/Post noise gates for each channel

* Easily accessible global controls for fast setup in different live situations

* Optional independent speaker cab sim for each output

* IR loading via the supporting software and mobile apps

* Fully programmable effects loop with serial and A/B modes. For use with external effects or combining with your head/combo’s

own preamp using the 4-cable method

* TONE CAPTURE for sampling your real amplifiers tonal characteristics and creating new digital preamp models

* Dedicated headphone output for use as a stand-alone practice unit

* Fully mappable MIDI IN and MIDI OUT for integration with other equipment

* USB and Bluetooth for connecting to PC, MAC and MOBILE APP for deep editing and amp selection

Preamp Channels: 12

Input: 1/4'' mono audio jack (impedance 500k)

Outputs: 1 x 1/4'' mono audio jack (impedance100Ω)

Effects Send: 1/4'' mono audio jack (impedance100Ω)

Effects Return: 1/4'' mono audio jack (impedance 500k)

USB: Type-B Female Connector

Sampling accuracy: 24bit

Signal to noise ratio: 103dB

Effects Loop: Mode 1 Serial ~ Mode 2 A/B

MIDI IN & OUT: 5 pin DIN connector

Sampling rate: 88.2KHz

Power requirements: 9V-12V DC 1A

Dimensions: 230mm x 130mm x 54mm

Weight: 1.18Kg

Accessories: 1 x USB Cable

Format: .WAV

Sampling rate: 44.1KHz

Sampling accuracy: 24bit

Max sample length: 23.2ms/1024 Points
