Yamaha DSR115

Yamaha DSR115
[klikni na sliku za uvećan prikaz]
  • Yamaha DSR115
  • Yamaha DSR115
Naša cena:
161.497,00 DIN
189.996,00 DIN





Korpa

Detaljnije o cenama

Garantovano najniže cene

Ukoliko pronađete povoljniju ponudu za ovaj instrument, dobićete ga od nas jeftinije za 10% od razlike u ceni!

Opis proizvoda:

The DSR115 is a compact, high-power 15" 2-way active loudspeaker system capable of achieving 136dB maximum peak SPL output. Equipped with high performance 48-bit DSP and top quality 1300W (LF 850W, HF 450W) Class-D amplifiers, it delivers sound with resolution at the highest level in its class and superb SPL performance. The DSR115 is perfect for live sound and installation applications that demand bass with extra punch and depth together with accurate high frequency response.

  • Ultra-precise 48-bit digital sound processing
  • D-CONTOUR (Dynamic-CONTOUR) multi-band dynamic processing
  • All-new 1300W Class-D amplifiers with PFC switching mode power supply
  • Maximum SPL 136dB peak
  • Extensive protection of the transducers, amplifiers and power supply from high performance DSP
  • Premium-grade, custom-designed transducers
  • Exclusive 90° × 60° CD Waveguide Horn
  • Compact and lightweight (28.0kg / 62lbs)
  • Stand and pole mountable, with 35mm pole sockets
  • Integrated M10 rigging points for suspended applications

Ultra-precise 48-bit digital sound processing

- Digital FIR-X tuning™ (linear phase FIR filter)
- High performance 48-bit DSP (76-bit accumulator)
- 24-bit discrete AD and DA converters

D-CONTOUR (Dynamic-CONTOUR) multi-band dynamic processing



All-new 1300W Class-D amplifiers with PFC* switching mode power supply

- LF: 850W
- HF: 450W
*Power Factor Correction

Maximum SPL 136dB peak



Extensive protection of the transducers, amplifiers and power supply from highperformance DSP



Premium-grade, custom designed transducers

- LF:High power 12" neodymium woofer with 3" voice coil
- HF:2" precision titanium diaphragm, neodymium, compression driver

Exclusive 90° × 60° CD Waveguide Horn



Compact and lightweight (28.0kg / 62lbs)



Stand and pole mountable, with 35mm pole sockets



Integrated M10 rigging points for suspended applications

Karakteristike:

Speaker type 15" 2-way, Bi-amp powered Speaker, Bass-reflex Type
Frequency response -10dB 45Hz ~ 20kHz
-3dB 55Hz ~ 18kHz
Nominal coverage H 90°
V 60°
Components LF 15" cone
HF 2" Titanium diaphragm compression driver
Output power 1300W (LF: 850W HF: 450W)
Maximum output level (1m; on axis) 136dB SPL
Processors D-CONTOUR (Dynamic CONTOUR)
I/O connetcors INPUT:XLR-3-31 x1 (Balanced) TRS Phone Jack x1 (Balanced), OUTPUT:XLR-3-32 x1 (Balanced), Parallel connection with INPUT
Dimensions W 442mm (17 4/8")
H 755mm (29 6/8")
D 423mm (16 4/8")
Net weight 28.0kg (62lbs)
Flying and mounting hardware 3 x M10 (TOP L/R 1pc each, Bottom rear 1pc)
Pole socket 35mm (Bottom Board)
Power consumption 100W
Crossover FIR-X tuning (linear phase FIR filter)
